12v-24v to 5V 3A Super Mini Super Size DC Step-Down Module With 97.5 percent Efficiency
Description:
Super Mini DC-DC Step-Down Converter Module is designed to convert a wide input voltage range of 12V to 24V (up to 28V max) down to a stable 5V output at up to 3A current. With a compact footprint and ultra-high efficiency (up to 97.5%), it’s ideal for space-constrained designs such as DIY electronics, robotics, Arduino projects, Raspberry Pi, automotive devices, and embedded systems. Module provides reliable voltage regulation and protection features, making it a solid choice for both hobbyist and industrial applications
Features:
1. Ultra-Compact Design
2. Wide Input Voltage Range
3. Stable 5V Output
4. High Output Current
5. Exceptional Efficiency:
6. Integrated Protection
7. Passive Cooling
8. Fast Switching Frequency
9. Easy Integration
10. Ideal for Battery or Solar Systems
Diagram:
Specifications:
| Input Voltage | 6V to 28V DC |
| Output Voltage | 5V ± 0.1V |
| Efficiency | Up to 97.5% |
| Switching Frequency | ~340 kHz |
| Operating Temp | -40°C to +85°C |
| Dimensions | 23mm × 17mm × 4mm |
| Weight | ~3g |
